CURT 13573

Product Details Attribute

Type	Receiver Size	Gross Trailer Weight Capacity (lbs)	Tongue Weight Capacity (lbs)	Weight Distribution Capacity (lbs)	Weight Distribution Tongue Weight Capacity (lbs)
Class I	1 1/4"	Up to 2,000	Up to 200
Class II	1 1/4"	Up to 3,500	Up to 350
Class III	2"	Up to 8,000	Up to 800	Up to 12,000	Up to 1,200
Class IV	2"	Up to 10,000	Up to 1,000	Up to 12,000	Up to 1,200
Class V - 2" Receiver	2"	16,000 to 17,000	2,400 to 2,550	17,000	2,400 to 2,550
Class V - 2 1/2" Receiver	2 1/2"	18,000 to 20,000	2,700	18,000 to 20,000	2,700

Features:

Engineered With A Vehicle-Specific Design For A Custom Fit

Tested For Safety In Accordance With SAE J684

Precisely Welded For Superior Strength

Protected By A Durable High-Gloss Black Powder Coat Finish And Co-Cured In A Rust-Resistant Liquid Bonderite Coating

Equipped With An Open-Back Receiver For Easy Cleaning

Trailer Hitch Class Capacities

Type Receiver Size Gross Trailer Weight Capacity (lbs) Tongue Weight Capacity (lbs) Weight Distribution Capacity (lbs) Weight Distribution Tongue Weight Capacity (lbs)

Class I
1 1/4" Up to 2,000 Up to 200

Class II
1 1/4" Up to 3,500 Up to 350

Class III
2" Up to 8,000 Up to 800 Up to 12,000 Up to 1,200

Class IV
2" Up to 10,000 Up to 1,000 Up to 12,000 Up to 1,200

Class V - 2" Receiver
2" 16,000 to 17,000 2,400 to 2,550 17,000 2,400 to 2,550

Class V - 2 1/2" Receiver
2 1/2" 18,000 to 20,000 2,700 18,000 to 20,000 2,700

All Curt Hitches are tested and validated to SAE specification J684 according to the particular model year application's Weight Carrying and Weight Distribution ratings.
Videos

All About Curt Trailer Hitches

How To Select A Trailer Hitch

Towing Parts

Additional Resources

Installation Instructions
How Much Can You Tow?

Warranty Information

Warranty Information:Limited Lifetime

CAPA CERTIFIED or NSF CERTIFIED

CAPA Certified or NSF Certified parts bear the seal of independent, third party organizations guaranteeing fitment and quality equal to original equipment. These parts may be required if your insurance company is paying for the repair.

Specifications
Finish	Gloss Black Powder Coat
Gross Trailer Weight	3500 lbs.
Receiver Tube Size	2.000 In.
WC Tongue Weight	350
Body Shape	Square
Drilling Required	Yes
Estimated Install Time	180 Minutes
Position	Rear
Visibility	Concealed
Weight Carrying Capacity	3500 lbs.
WD Tongue Weight	400 lbs.
Weight Distribution	4000 lbs.
